Overview
Select Model:
- Releases - list of all releases
- Building manual - how to build Dasharo for Protectli FW6
- Installation manual - how to install Dasharo for Protectli FW6
- Hardware configuration matrix - definition of hardware configuration used during validation
- Test matrix - validation scope for the Protectli FW6
The Vault is a small form network appliance built for use as a firewall / router, virtualization platform, a daily-driven personal computer, and more. The V1000 series feature an Intel Jasper Lake CPU, soldered down LPDDR4X memory, Intel i225-V/i226-V 2.5G Ethernet ports, 4x USB-A 3.x ports, eMMC, PCIe NVMe storage, M.2 WIFI and WWAN slots, serial console over USB-C and a firmware TPM.
- V1210 - Intel® Celeron® N5105, 2x i225/i226, 4GB LPDDR4X
- V1211 - Intel® Celeron® N5105, 2x i225/i226, 8GB LPDDR4X
- V1410 - Intel® Celeron® N5105, 4x i225/i226, 8GB LPDDR4X
- V1610 - Intel® Pentium® Silver N6005, 6x i225/i226, 16GB LPDDR4X
Documentation sections
- Releases
- groups information about all releases.
- Building manual
- describes how to build Dasharo for Protectli V1000 series.
- Initial deployment
- describes initial Dasharo deployment methods (i. e. flashing new firmware) for Protectli V1000 series.
- Firmware update
- explains supported Dasharo open-source firmware update methods.
- Recovery
- gathers information on how to recover the platform from potential failure.
- Hardware configuration matrix
- describes the platform's hardware configuration used during the Dasharo firmware validation procedure.
- Test matrix
- describes validation scope used during Dasharo firmware validation procedure.
The Vault is a small form network appliance built for use as a firewall / router, virtualization platform, a daily-driven personal computer, and more. The VP46XX is the second platform of the Vault Pro series with higher performance and newer technology than the original FW6 series.
The VP46XX features an Intel 10th Generation CPU, 2x DDR4 DIMM modules, 6x Intel i225-V 2.5G Ethernet ports, PCIe x4/SATA NVMe storage, LPC TPM, M.2 WIFI and WWAN slots.
- VP4630 - Intel Core i3-10110U
- VP4650 - Intel Core i5-10210U
- VP4670 - Intel Core i7-10810U (both v1 and v2 versions, see the Intel FSP repo for details)
Starting with Dasharo v1.0.19 Intel ME (Management Engine) is soft-disabled.
For more information please refer to the references below.
References
Documentation sections
- Releases - groups information about all releases.
- Building manual - describes how to build Dasharo for NovaCustom NV4x.
- Initial deployment - describes initial Dasharo deployment methods (i. e. flashing new firmware) for Protectli VP46XX.
- Firmware update - explains supported Dasharo open-source firmware update methods.
- Recovery - gathers information on how to recover the platform from potential failure.
- Hardware configuration matrix - describes the platform's hardware configuration used during the Dasharo firmware validation procedure.
- Test matrix - describes validation scope used during Dasharo firmware validation procedure.
- Post-installation setup
The Vault Pro is a small form network appliance built for use as a firewall / router, virtualization platform, a daily-driven personal computer, and more. The VP2410 is based on a 4 network port design that leverages a low power, but versatile Intel Celeron J4125 CPU.
The VP2410 can accommodate up to 16GB DDR4 RAM and 2TB m.2 SATA SSD storage drive. The built-in 8GB eMMC module can be used for booting a light-weight OS for example, or for use as optional storage.
VP2410 specification:
- Intel Celeron® J4125 Quad Core at 2 GHz (Burst up to 2.7 GHz)
- 4 Intel® Gigabit Ethernet NIC ports
- 8GB eMMC module on board
- Intel® AES-NI support
- Fanless and Silent
- Included 12v Power Supply, VESA mount kit, Serial Console Cable, SATA data and power cables for internal SSD, Quick Start Guide
On VP2410 Intel ME (Management Engine) is not supported by coreboot causing Intel ME to enter recovery mode giving similar results to disabled ME.
For more information please refer to the references below.
References
Documentation sections
- Releases - groups information about all releases.
- Building manual - describes how to build Dasharo for Protecli 2410.
- Initial deployment - describes initial Dasharo deployment methods (i. e. flashing new firmware) for Protectli VP2410.
- Recovery - gathers information on how to recover the platform from potential failure.
- Hardware configuration matrix - describes the platform's hardware configuration used during the Dasharo firmware validation procedure.
- Test matrix - describes validation scope used during Dasharo firmware validation procedure.
The Vault Pro is a small form network appliance built for use as a firewall / router, virtualization platform, a daily-driven personal computer, and more. The VP2420 is based on a 4 x 2.5 G network port design that leverages a low power, but versatile Intel Celeron J6412 CPU.
The VP2420 can accommodate up to 32 GB DDR4 RAM and 2 TB M.2 SATA SSD storage drive (Note: The VP2420 supports M.2 SATA drives, not NVMe drives). The built-in 8 GB eMMC module can be used for booting a light-weight OS for example, or for use as optional storage.
VP2410 specification:
- Intel Celeron® J6412 Quad Core at 2 GHz (Burst up to 2.6 GHz)
- 4 Intel® 2.5 Gigabit Ethernet NIC ports
- M.2 SATA SSD Slot (Note: This device does not support NVMe drives)
- 8 GB eMMC module on board
- Intel® AES-NI support
- Fanless and Silent
- Included 12v Power Supply, VESA mount kit, Serial Console Cable, SATA data and power cables for internal SSD, Quick Start Guide
Starting with Dasharo v1.2.0, Intel ME (Management Engine) is soft-disabled by default.
For more information please refer to the references below.`
References
Documentation sections
- Releases - groups information about all releases.
- Building manual - describes how to build Dasharo for Protecli 2420.
- Initial deployment - describes initial Dasharo deployment methods (i. e. flashing new firmware) for Protectli VP2420.
- Recovery - gathers information on how to recover the platform from potential failure.
- Hardware configuration matrix - describes the platform's hardware configuration used during the Dasharo firmware validation procedure.
- Test matrix - describes validation scope used during Dasharo firmware validation procedure.
The Vault is a small form network appliance built for use as a firewall / router, virtualization platform, a daily-driven personal computer, and more. The VP6630/VP6650/VP6670 feature an Intel Alder Lake-P CPU, 2x DDR5 SODIMM memory, Intel i225-V/i226-V 2.5G Ethernet ports, 2x SFP Intel X710, 4x USB-A ports (1x 3.1, 3x 2.0), one internal USB-A 3.1, 1x USB-C with PD, PCIe NVMe storage, M.2 WIFI and WWAN slots, 2x serial console over USB-C and RJ45, SPI TPM, 2 CPU fans.
- VP6630 - Intel® Core™ i3 -1215U
- VP6650 - Intel® Core™ i5 -1235U
- VP6670 - Intel® Core™ i7 -1255U
On VP66XX Intel ME (Management Engine) is disabled by using the HAP bit.
Documentation sections
- Releases - groups information about all releases.
- Building manual - describes how to build Dasharo for Protectli VP6630/VP6650/VP6670.
- Initial deployment - describes initial Dasharo deployment methods (i. e. flashing new firmware) for Protectli VP6630/VP6650/VP6670.
- Firmware update - explains supported Dasharo open-source firmware update methods.
- Recovery - gathers information on how to recover the platform from potential failure.
- Hardware configuration matrix - describes the platform's hardware configuration used during the Dasharo firmwarevalidation procedure.
- Test matrix - describes validation scope used during Dasharo firmware validation procedure.
- Post-installation setup
